OEM Small Wet Magnetic Separator Strong Water Beneficiation Magnetic Iron Remover Limonite Drum Wet Wet Magnetic Magnetic Separator mining, waste-to-energy plants

Nama merek:	WeSeW
Nomor Model:	CX-717
MOQ:	1 buah
harga:	Price Negotiation
Ketentuan Pembayaran:	T/T, Western Union
Kemampuan Penyediaan:	1000000pcs per bulan

Informasi detil

Deskripsi Produk

Informasi detil

Tempat asal:

CINA

Sertifikasi:

CE,UL

Kekuatan Medan Magnet:

≥3000GS

Voltase:

220v

Disesuaikan:

Disesuaikan

Komponen inti:

Bantalan

Frekuensi:

50Hz

Kustomisasi:

Tersedia Permintaan Khusus

Jenis:

Pemisah magnetik

Bahan:

Baja Tahan Karat

Kemasan rincian:

Kasus kayu

Menyediakan kemampuan:

1000000pcs per bulan

Menyoroti:

small wet magnetic separator

water beneficiation magnetic iron remover

limonite drum wet magnetic separator

Deskripsi Produk

OEM Small Wet Magnetic Separator

Strong Water Beneficiation Magnetic Iron Remover for Mining and Waste-to-Energy Plants

The magnetic separator is one of the most versatile industrial machines, designed for separating substances with magnetic differences. This wet magnetic separator is particularly effective for processing materials in mining, timber, kiln, chemistry, and food industries.

Key Applications

Wet or dry magnetic separation of manganese ore, magnetite, pyrrhotite, roasted ore, ilmenite, and hematite
Iron removal from coal, non-metallic minerals, and building materials
Processing materials with particle sizes below 50mm
Ideal for mining operations and waste-to-energy plants

Technical Specifications

The permanent magnetic system uses high-quality ferrite materials or rare earth magnetic steel compounds. Modern roll-type designs achieve magnetic field intensities up to 1650mT - the highest currently available in industrial magnetic separators.

Operating Principle

The separation process begins when pulp flows into the tank through the feeding box. Under magnetic influence:

Magnetic particles form clusters or chains that move toward magnetic poles
These clusters adhere to the rotating cylinder while non-magnetic materials fall away
Concentrate moves to the weakest magnetic zone for collection
Tailings exit with the remaining pulp flow

Product Images
